Perfiles comerciales
|
Medidas |
Peso Kg/m |
Coef. conversión (kg/m) |
|---|---|---|
|
6 |
0.22 |
0.23 |
|
8 |
0.39 |
0.41 |
|
10 |
0.62 |
0.64 |
|
12 |
0.89 |
0.92 |
|
14 |
1.21 |
1.26 |
|
16 |
1.58 |
1.64 |
|
18 |
2.00 |
2.08 |
|
20 |
2.47 |
2.57 |
|
22 |
2.98 |
3.10 |
|
25 |
3.85 |
4.00 |
|
30 |
5.55 |
5.77 |
|
32 |
6.31 |
6.56 |
|
35 |
7.55 |
7.85 |
|
40 |
9.68 |
10.07 |
|
45 |
12.48 |
12.98 |
|
50 |
15.41 |
15.41 |
|
60 |
20.20 |
23.09 |
|
Medidas |
Peso Kg/m |
Coef. conversión (kg/m) |
|---|---|---|
|
10 |
0.79 |
0.82 |
|
12 |
1.13 |
1.18 |
|
14 |
1.54 |
1.60 |
|
16 |
2.01 |
2.07 |
|
18 |
2.27 |
2.62 |
|
20 |
3.14 |
3.23 |
|
22 |
3.80 |
3.91 |
|
25 |
4.91 |
5.06 |
|
30 |
7.07 |
7.27 |
|
35 |
9.62 |
9.91 |
|
40 |
12.56 |
12.98 |
|
45 |
15.90 |
16.38 |
|
50 |
19.63 |
20.19 |
|
Medidas |
Peso Kg/m |
Coef. conversión (kg/m) |
Sección en mm. b |
Sección en mm. e |
Sección en cm2 |
|---|---|---|---|---|---|
|
20×3 |
0.88 |
0.92 |
20 |
3 |
1.15 |
|
25×3 |
1.12 |
1.16 |
25 |
3 |
1.43 |
|
30×3 |
1.36 |
1.62 |
30 |
3 |
1.74 |
|
35×4 |
2.09 |
2.17 |
35 |
4 |
2.67 |
|
40×4 |
2.42 |
2.52 |
40 |
4 |
3.08 |
|
45×5 |
3.38 |
3.52 |
45 |
5 |
4.30 |
|
50×5 |
3.77 |
3.92 |
50 |
5 |
4.90 |
|
55×6 |
4.95 |
5.23 |
55 |
6 |
6.31 |
|
60×6 |
5.42 |
5.64 |
60 |
6 |
6.91 |
|
65×7 |
6.93 |
7.21 |
65 |
7 |
8.73 |
|
70×7 |
7.38 |
7.68 |
70 |
7 |
9.40 |
|
75×8 |
8.95 |
9.31 |
75 |
8 |
11.5 |
|
80×8 |
9.63 |
10.02 |
80 |
8 |
12.3 |
|
90×9 |
12.20 |
12.53 |
90 |
9 |
15.5 |
|
100×10 |
15.0 |
15.60 |
100 |
10 |
19.2 |
|
120×12 |
21.6 |
22.46 |
120 |
12 |
27.5 |
|
150×15 |
33.8 |
35.15 |
150 |
15 |
43.0 |
|
200×20 |
59.9 |
62.30 |
200 |
20 |
76.8 |
|
Medidas |
Peso Kg/m |
Coef. conversión (kg/m) |
Sección en mm. h |
Sección en mm. b |
Sección en mm. e |
|---|---|---|---|---|---|
|
25 |
1.29 |
1.42 |
25 |
25 |
3.5 |
|
30 |
1.77 |
1.84 |
30 |
30 |
4.0 |
|
35 |
2.33 |
2.42 |
35 |
35 |
4.5 |
|
40 |
2.96 |
3.08 |
40 |
40 |
5.0 |
|
45 |
3.67 |
4.16 |
45 |
45 |
5.5 |
|
50 |
4.44 |
4.62 |
50 |
50 |
6.0 |
|
60 |
6.23 |
6.48 |
60 |
60 |
7.0 |
|
70 |
8.32 |
8.65 |
70 |
70 |
8.0 |
|
80 |
10.70 |
11.13 |
80 |
80 |
9.0 |
|
Medidas |
Peso Kg/m |
Coef. conversión (kg/m) |
Sección en mm. h |
Sección en mm. b |
Sección en mm. e |
Sección en mm. e1 |
Sección en cm2 |
|---|---|---|---|---|---|---|---|
|
40×20 |
2.6 |
30.03 |
40 |
20 |
4.0 |
5.0 |
3.2 |
|
50×35 |
3.7 |
4.10 |
50 |
25 |
4.5 |
6.0 |
4.8 |
|
60×30 |
5.2 |
5.39 |
60 |
30 |
5.0 |
6.0 |
6.6 |
|
Espesores |
Peso kg/m |
Coef. conversión |
Peso kg/m |
Coef. conversión |
Peso kg/m |
Coef. conversión |
|
Medidas |
12 |
12 |
14 |
14 |
16 |
16 |
|---|---|---|---|---|---|---|
|
3 |
0.283 |
0.30 |
0.33 |
0.35 |
0.377 |
0.40 |
|
4 |
0.377 |
0.40 |
0.44 |
0.46 |
0.502 |
0.53 |
|
5 |
0.55 |
0.58 |
0.628 |
0.66 |
||
|
6 |
0.659 |
0.69 |
0.756 |
0.79 |
||
|
MEDIDAS |
18 |
18 |
20 |
20 |
25 |
25 |
|
3 |
0.424 |
0.45 |
0.471 |
0.49 |
0.589 |
0.62 |
|
4 |
0.565 |
0.59 |
0.628 |
0.66 |
0.785 |
0.82 |
|
5 |
0.707 |
0.74 |
0.785 |
0.82 |
0.981 |
1.03 |
|
6 |
0.818 |
0.86 |
0.942 |
0.99 |
1.18 |
1.24 |
|
7 |
1.14 |
1.37 |
1.42 |
|||
|
8 |
1.31 |
1.57 |
1.63 |
|||
|
10 |
1.63 |
1.96 |
2.04 |
|||
|
12 |
2.36 |
2.45 |
||||
|
MEDIDAS |
30 |
30 |
35 |
35 |
40 |
40 |
|
3 |
0.707 |
0.74 |
0.824 |
0.87 |
0.942 |
0.99 |
|
4 |
0.942 |
0.99 |
1.10 |
1.16 |
1.26 |
1.32 |
|
5 |
1.18 |
1.24 |
1.37 |
1.44 |
1.57 |
1.65 |
|
6 |
1.41 |
1.48 |
1.68 |
1.73 |
1.88 |
1.97 |
|
7 |
1.65 |
1.72 |
1.92 |
2.00 |
2.20 |
2.29 |
|
8 |
1.88 |
1.96 |
2.20 |
2.29 |
2.51 |
2.61 |
|
10 |
2.36 |
2.45 |
2.75 |
2.86 |
3.14 |
3.27 |
|
12 |
2.83 |
2.94 |
3.30 |
3.43 |
3.77 |
3.92 |
|
14 |
3.85 |
4.00 |
4.40 |
4.58 |
||
|
15 |
4.12 |
4.28 |
4.71 |
4.90 |
||
|
16 |
4.40 |
4.53 |
50.02 |
5.17 |
||
|
18 |
4.95 |
5.10 |
5.62 |
5.82 |
||
|
20 |
5.50 |
5.67 |
6.28 |
6.47 |
||
|
25 |
7.85 |
8.09 |
||||
|
30 |
9.42 |
9.70 |
||||
|
MEDIDAS |
45 |
45 |
50 |
50 |
60 |
60 |
|
3 |
1.06 |
1.11 |
||||
|
4 |
1.41 |
1.48 |
1.57 |
1.65 |
||
|
5 |
1.77 |
1.86 |
1.96 |
2.06 |
2.36 |
2.48 |
|
6 |
2.12 |
2.23 |
2.36 |
2.48 |
2.83 |
2.97 |
|
7 |
2.47 |
2.57 |
2.75 |
2.86 |
3.30 |
3.43 |
|
8 |
2.83 |
2.94 |
3.14 |
3.27 |
3.77 |
3.92 |
|
10 |
3.53 |
3.67 |
3.93 |
4.09 |
4.71 |
4.90 |
|
12 |
4.24 |
4.41 |
4.71 |
4.90 |
5.65 |
5.88 |
|
14 |
4.95 |
5.15 |
5.40 |
5.62 |
6.59 |
6.85 |
|
15 |
5.30 |
5.51 |
5.89 |
6.13 |
7.03 |
7.35 |
|
16 |
5.65 |
5.82 |
6.28 |
6.47 |
7.54 |
7.77 |
|
18 |
6.36 |
6.55 |
7.06 |
7.27 |
8.48 |
8.73 |
|
20 |
7.07 |
7.28 |
7.85 |
8.09 |
9.42 |
9.70 |
|
25 |
8.83 |
9.09 |
9.81 |
10.10 |
11.8 |
12.15 |
|
30 |
10.60 |
10.92 |
11.8 |
12.15 |
14.1 |
14.52 |
|
40 |
15.7 |
16.17 |
18.8 |
19.36 |
||
|
MEDIDAS |
70 |
70 |
80 |
80 |
90 |
90 |
|
5 |
2.75 |
2.89 |
3.14 |
3.30 |
3.53 |
3.71 |
|
6 |
3.30 |
3.47 |
3.77 |
3.96 |
4.24 |
4.45 |
|
7 |
3.85 |
4.00 |
4.40 |
4.58 |
||
|
8 |
4.40 |
4.58 |
5.02 |
5.22 |
5.65 |
5.88 |
|
10 |
5.50 |
5.72 |
6.28 |
6.53 |
7.07 |
7.35 |
|
12 |
6.59 |
6.85 |
7.54 |
7.84 |
8.48 |
8.82 |
|
14 |
7.69 |
8.00 |
8.79 |
9.14 |
9.89 |
10.29 |
|
15 |
8.24 |
8.57 |
9.42 |
9.80 |
10.6 |
11.02 |
|
16 |
8.79 |
9.05 |
10.0 |
10.30 |
11.3 |
11.64 |
|
18 |
9.89 |
10.19 |
11.3 |
11.64 |
||
|
20 |
11.0 |
11.33 |
12.6 |
12.98 |
14.1 |
14.52 |
|
25 |
13.7 |
14.11 |
15.7 |
16.17 |
17.7 |
18.23 |
|
30 |
16.5 |
17.00 |
18.8 |
19.36 |
21.2 |
21.84 |
|
40 |
22.0 |
22.66 |
25.1 |
25.85 |
28.3 |
29.15 |
|
MEDIDAS |
100 |
100 |
110 |
110 |
120 |
120 |
|
6 |
4.71 |
4.95 |
5.18 |
5.44 |
5.65 |
5.93 |
|
8 |
6.23 |
6.48 |
6.91 |
7.19 |
7.54 |
7.84 |
|
10 |
7.85 |
8.16 |
8.61 |
8.95 |
9.42 |
9.80 |
|
12 |
9.42 |
9.80 |
10.4 |
10.82 |
11.3 |
11.75 |
|
14 |
11.0 |
11.44 |
12.1 |
12.58 |
13.2 |
13.73 |
|
15 |
11.8 |
12.27 |
13.0 |
13.52 |
14.1 |
14.66 |
|
16 |
12.6 |
12.98 |
13.8 |
14.21 |
15.1 |
15.55 |
|
18 |
14.1 |
14.52 |
15.5 |
15.97 |
17.0 |
17.51 |
|
20 |
15.7 |
16.17 |
17.3 |
17.82 |
18.8 |
19.36 |
|
25 |
19.6 |
20.19 |
21.6 |
22.25 |
13.6 |
24.31 |
|
30 |
23.6 |
24.31 |
25.9 |
26.68 |
28.3 |
29.15 |
|
40 |
31.4 |
32.34 |
34.5 |
35.54 |
||
|
MEDIDAS |
130 |
130 |
140 |
140 |
150 |
150 |
|
6 |
6.12 |
6.43 |
6.60 |
6.92 |
7.06 |
7.41 |
|
8 |
8.16 |
8.49 |
8.79 |
9.14 |
9.42 |
9.80 |
|
10 |
10.2 |
10.61 |
11.0 |
11.44 |
11.8 |
12.27 |
|
12 |
12.2 |
12.69 |
13.2 |
13.73 |
14.1 |
14.66 |
|
14 |
14.3 |
14.87 |
15.4 |
16.02 |
16.5 |
17.16 |
|
15 |
15.3 |
15.91 |
16.5 |
17.16 |
17.7 |
18.41 |
|
16 |
16.3 |
16.79 |
17.6 |
18.13 |
18.8 |
19.36 |
|
20 |
20.4 |
21.01 |
22.0 |
22.66 |
23.6 |
24.31 |
|
25 |
25.5 |
26.27 |
27.5 |
28.33 |
29.4 |
30.28 |
|
30 |
30.6 |
31.52 |
33.0 |
33.99 |
35.3 |
36.36 |
|
MEDIDAS |
160 |
160 |
180 |
180 |
200 |
200 |
|
8 |
10.0 |
10.40 |
11.3 |
11.75 |
12.6 |
13.06 |
|
10 |
12.6 |
13.10 |
14.1 |
14.66 |
15.7 |
16.33 |
|
12 |
15.1 |
15.70 |
17.0 |
17.68 |
18.8 |
19.59 |
|
14 |
17.6 |
18.30 |
19.8 |
20.59 |
22.0 |
22.86 |
|
15 |
18.3 |
19.03 |
21.2 |
22.05 |
23.6 |
24.49 |
|
16 |
20.1 |
20.70 |
22.6 |
23.28 |
25.1 |
25.87 |
|
20 |
25.1 |
25.85 |
28.0 |
29.15 |
31.4 |
32.34 |
|
25 |
31.4 |
32.34 |
35.3 |
36.36 |
